THE STRONGEST HAMMER ON THE MARKET

OUTPERFORMING 500 HP PILING RIGS ACROSS EUROPE.

CRAMEC has managed to take over 40 year old hydraulic “Hand-brake” off. CRAMEC’s UP/DOWN prototype hammer has made a unique mark in the field of piling by delivering unmatched performance in Germany, England, Ireland, Tallinn, and Joensuu, Finland. It has achieved tasks that even a 550-horsepower piling rig was unable to complete.

Following the successful testing and completion of four prototypes, full-scale mass production commences in 2026.

USE CASES

AS A DEMOLITION HAMMER

  • It has the strongest impact energy in it’s weight-class
  • The only demolition hammer with “ShockWave“-System, increasing teh demolition productivity
  • 20-30% better hydraulic efficiency, less hydraulic oil heating and almost none hydraulic pressure peaks.

AS A STEEL-PILE DRIVER/EXTRACTOR

  • Only hammer capable of hitting up
  • Can finish the job which Sheet-Pile Driver has failed to do, real money maker in those jobs

AS A FOUNDATION HAMMER/EXTRACTOR

  • CRAMEC extracts the failed foundation piles for reuseadjustable blow-energy
  • Final hits ffrom the cabine
  • Only demolition hammer able to do final hits (PDA)

TECHNICAL DATA

Model UD-3000/4000
Weight 1400 kg
Without Pile-Grip and tilting device 1200 kg
UP/DOWN version 1600 kg
Impact energy Portably adjustable
Oil-flow 50–250 l/min
Blows a minute 20–250
Working pressure 200 bar
Total length, including working tool 2300 mm
Time needed to change hitting direction 10–15 seconds
